SD FM-S-A-L4.50-C100-SP15
Stepped cylindrical shanks for interchangeable solid carbide face milling heads.
| Connection Thread Nominal Size Workpiece Side (THSZWS) | M5x0.5 | Functional Length (LF) | 4.693″ |
| Connection Diameter Machine Side (DCONMS) | 1″ | Weight of Item (WT) | 0.95 lbs |
| Material | Carbide | Measurement Type | Inch |
| Overall Length (OAL) | 4.693″ | Body Material | Steel |
| Body Length (LB) | 0.398″ | Connection Code Machine Side (CCMS) | Cylindrical |
Product Features
| Family Description | Stepped cylindrical shanks for interchangeable solid carbide face milling heads. | Country of Origin | Israel |
| Remarks | Apply lubricant to the clamping screw |
Shipping Info
Package Weight
1.190
